DLS RCW12 Reference Series 12" 4 Ohm 1000 Watt Car Subwoofer

Overview

RCW12 is a brand new12" subwoofer in Reference series with the latest technology giving the sub fantastic sound quality

Dual 4 ohm voice coils, Use single voice coil connection or connect in parallel to 2 ohms for maximum output power from your mono amplifier

Specifications

• Woofer size 12" (30 cm)
• Impedance 2 x 4 ohm
• Power handling capacity 400 W RMS
• Max power handling capacity 800 W
• Peak power 1000 W
• Frequency range 22 - 1000 Hz
• Sensitivity 86,5 dB (1W/1m)
• Magnet size 188 mm (7,4")
• Outer diameter of woofer 315 mm (12,4")
• Mounting depth 155 mm ( 6,1")
• Mounting hole 284 mm ( 11,18")
• X-max +- 9 mm (0,35")
• Weight 9,5 kg (20,9 lbs)
