RL-AE10 - Designed & Engineered in the USA

Overview

The DD Audio RL-AE10 is an active subwoofer with a 10″ element in the DD Audio Redline range, two passive radiators and a 200W / RMS amplifier. Due to its small size, this subwoofer can be placed, for example, in the footwell of the auxiliary driver (Chest damper), under the bench, in the trunk or on the hat rack.

The 10″ subwoofer element is mounted in a sturdy housing made of die-cast aluminum. The element is protected by a protective grille. Also includes mounting brackets and a bass level remote control. It is also possible to connect to the car's original player thanks to the signal-level input of the signal.

Features

• Active Subwoofer with 10" Bass
• Two Passive Emitters
• Aluminum Housing
• Element Cone Aluminum

Specifications

• Operating Voltage: 10-16V
• Continuous Wattage @ 2 Ohm: 200W
• Dynamic Wattage: 700W
• Max Current Draw: 30A
• Frequency Response: 20-150Hz
• RCA Input Voltage Sensitivity: 0.5V
• High Level Input Sensitivity: 110mV
• Low Pass Filter: 50-150Hz
• Subsonic Filter: 20Hz (Fixed)
• Bass Boost: 0-12dB @ 45Hz
• Remote Subwoofer Control: Yes
• Power Wire Gauge: 8"
• Dimensions: 15 x 11.25 x 3.0" (381 x 285.75 x 76.2mm)
