Epson EB-PU1007W WUXGA 3LCD Laser Projector with 4K Enhancement

Delivering best-in-class color brightness, with 7,000 lumens of color brightness and 7,000 lumens of white brightness, this 3-chip, 3LCD projector features a virtually maintenance-free 20,000 hour laser light source and air filter.

Full HD WUXGA resolution and 4K Enhancement Technology (1920 x 1200 x 2) mean you get crystal-clear, lifelike images. Built-in NFC function reduces the time to install and commission multiple projectors. And a clip-on optional external camera allows access to powerful automated tools including auto color calibration, screen matching of multiple projectors, tiling assist for edge blends, and the stacking assist function.

NOTE: Mount sold separately.

OVERVIEW

• 7,000 lumens color/white brightness
• Native WUXGA with 4K Enhancement Technology
• Laser light source — up to 20,000 hours of use
• 11 optional powered lenses
• NFC function built-in
• Model: V11HA34920
• Lifelike images — high native contrast ratio, HDR support and scene adaptive gamma correction for more realistic images and easy-to-read presentations
• Optional external air filter — extend the filter maintenance cycle in dusty environments
• Dynamic projection capabilities — advanced built-in Edge Blending, image warping and shape overlay features for a variety of applications; direct content playback from USB storage media
• Customized performance — brightness modes to maximize light source life and provide a consistent brightness level
• Powerful remote management — control and monitor projector status via the Epson Projector Management app for Windows

Best-in-class color brightness
7,000 lumens color/white brightness from a compact large-venue laser projector.

Exceptional widescreen display
Native WUXGA with 4K Enhancement Technology1 (1920 x 1200 x 2); accepts 4K content and provides up to 4.6 million pixels onscreen

Worry-free operation
Virtually maintenance free 20,000 hour laser light source and air filter

Simplified installation features
11 optional powered lenses including ultra short-throw with .35 throw; inputs including HDBaseT™ and HDMI® (HDCP 2.3)

NFC function built-in5
Reduce installation time of multiple projectors; read and write setting information using Epson’s mobile app

Clip-on optional external camera
Access powerful automated tools including auto color calibration6, screen matching of multiple projectors, tiling assist for edge blends8, and the stacking assist9 function.

SPECIFICATIONS

Projection System – 3LCD Technology, RGB liquid crystal shutter
LCD Panel –  0.76 inch with C2 Fine
Image – Color
Light Output –  7,000 Lumen- 4,900 Lumen (economy) In accordance with IDMS15.4
White Light Output –  7,000 Lumen – 4,900 Lumen (economy) In accordance with ISO 21118:2012
Portrait Colour Light Output –  7,000 lm
Portrait White Light Output – 7,000 lm
Resolution – WUXGA, 1920 x 1200, 16:10
High Definition – 4K enhancement
Aspect Ratio – 16:10
Contrast Ratio –  Over 2,500,000 : 1
Native Contrast –  2,000 : 1
Light source –  Laser
Laser Light source –  20,000 hours Durability High, 30,000 hours Durability Eco
Keystone Correction –  Manual vertical: ± 45 °, Manual horizontal ± 30 °
Colour Video Processing –  10 Bits
Colour Reproduction –  Upto 1.07 billion colours
Throw Ratio –  0.35 – 10.11:1
Zoom –  Motorized
Lens –  Optical
Projection Lens Focus –  Motorized
Interchangeable Lens –  Yes
Standard Lens –  Not included
Power consumption –  431 Watt, 366 Watt (economy), 0.5 Watt (standby)
Heat Dissipation –  1,465.4 BTU/hour (max)
Supply Voltage –  AC 100 V – 240 V, 50 Hz – 60 Hz
Product dimensions –  545‎ x 436 x 189 mm (Width x Depth x Height)
Product weight –  16.3 kg
Noise Level –  Normal: 33 dB (A) – Economy: 29 dB (A)
Supported Temperature –  Storage -10° C – 60° C
Supported Humidity –  Operation 20% – 80%, Storage 10% – 90%
If the projector is suspended from a ceiling or wall mount and installed in an environment with heavy oil smoke or places where oils or chemicals are volatilized, places where a lot of smoke or bubbles are used for event staging, or where aroma oils are frequently burned, it can make certain parts of our products susceptible to a material degradation which over time could break and cause the projector to drop from the ceiling.

If you are concerned about the environment in which your projector is installed, or if you have any other questions, please contact our support department and they can provide additional assistance.

Included Software –  iProjection, Epson Projector Content Manager
Options  –  Wireless LAN unit
What’s in the box –  Cable cover, Power cable, Remote control incl. batteries, User’s Manual Set, Warranty Documents
Room Type / Application –  Boardroom, Large Meeting Room / Auditorium, Meeting room / Classroom, Projection Mapping, Rental / Staging, Signage / Retail, Visitor Attraction
Positioning  Ceiling Mounted, Desktop, Flying Frame
Colour –  White / Black
