CD Player

Marantz HDAM Technology
Marantz developed its own discrete circuit boards to replace standard ICs. These HDAMs consist of discrete surface mount components with short mirror image L/R signal paths. These devices do the same thing as the widely used Op-Amps but outperform these designs dramatically in terms of the Slew Rate and reduced noise level, resulting in more dynamic, accurate and detailed sound. In the CD6007, the proprietary HDAM-SA2 circuit improves on its previous HDAM module for an even more stable power supply. The idling current stability is less influenced by power transistor temperatures to maintain sound performance even at high level output.

Reference Quality D/A Conversion
The CD6007 features a new Hi-Res D/A conversion. It is equipped with a reference class AK4490 D/A converter, offering two selectable filter options, and provides up to 192-kHz/24-bit and DSD 5.6MHz resolution for optimum musical fidelity with tight bass, pleasant mids and smooth extended highs for CD playback and Hi-Res formats from USB memory devices.

Headphone Amplifier with HDAM-SA2 and Headphone Amp Gain Setting (Low/Mid/High)
Compared to the CD6006, the CD6007 offers an improved and redesigned headphone amplifier section. The CD6007 inherits the exclusive Marantz HDAM-SA2 circuit with three gain settings (Low/Mid/High) for a perfect match with almost any brand of headphones for an optimal solo listening experience. However, if you prefer, the headphone amp is also equipped with an “Off Circuit” function that automatically turns off the headphone amplifier when a headphone is not connected to the unit to avoid any unwanted interference or noise.

Plays Hi-Res Audio
The CD6007 can playback MP3, WMA, AAC and WAV, FLAC HD, ALAC, AIFF (up to 192-kHz/24-bit) and DSD (up to 5.6MHz) files from a connected USB storage device.

The Most Musical Sound
Engineered and extensively tuned by a team drawing on more than 65 years of Hi-Fi expertise, the CD6007 provides exceptional performance for your audio collection. Whether digital or analogue, enjoy the most musical sound from any source.

Digital Filter
The CD6007 introduces a new selectable digital filter option. This two-mode filter (Filter1/Filter2) allows optimized reproduction of digital music content using the new AK4490 D/A converter to your taste. Filter 1 is a slow roll-off present that improves deep stereo imaging while Filter 2 is a sharp roll-off filter for more precise imaging reproduction.

Specifications:
-CD Compatibility: CD / CD-R/RW / SA-CD / WMA / MP3 / AAC
-Data Disc Compatibility: DSD / WAV / ALAC
-DAC operation mode: USB-B / Coax / Optical
-Asynchronous mode rear USB
-Bit-perfect transmission
-USB-B DSD Audio Streaming (Do): DSD2.8 / DSD5.6

-Signal isolator for DAC Mode operation
-HDAM version HDAM+HDAM SA2
-Power Transformer: Toroidal / El              - / o
-High Grade Audio Components
-Customised Components
-Symmetric circuit layout
-Copper plated chassis
-Extra metal plate for chassis strengthening
-Digital out off / Audio EX Mode o / -
-Headphone: Standard / Buffer / Current Feedback
