Multi Source CD Player

Description
This is a unique device reflecting an ingenious design philosophy, as it combines the classic music source of CD player with the ability to play digital music formats from a vast range of sources!
With this aim in mind we developed a main board which can process five different digital sources at superb quality and devoid of jitter; a new streaming client (SCL), which is a network enabled processor board featuring WLAN, LAN and USB interfaces; a high quality digital tuner; a high quality CD mechanism and a digital connecting board fitted with five high-quality digital SP/DIF inputs, a computer USB input and an aptX® Bluetooth module. These features permit the T+A MP 1000 E to access everything which delivers music: Internet radio with internet radio; UPnP network music servers and USB memory media; FM, FM-HD and DAB+ radio; CD`s and music from computers, laptops or other external sources via the SPDIF inputs. HD Bluetooth streaming from mobile devices is also possible at superb quality. The USB Device Mode input is intended for streaming music files from a computer and is designed it to be of exceptionally high quality. It can process data rates up to 32bit/384kHz for PCM and DSD 256 (12 MHz). The heart of the T+A MP 1000E is its dual mono differential converter (DAC) combined with audiophile high bandwidth analogue output stages. It even possesses a sophisticated clock resynchronisation circuit to eliminate jitter and all forms of external interference. It is this combination which is responsible for the MP 1000 E’s incredibly natural “analogue sound” which is refreshingly different from many other digital players.

Specification
-Frequency Response-2 Hz – 20 kHz / 100 dB. PCM 44.1 kSps: 2 Hz - 20 kHz, PCM 48 kSps: 2 Hz - 22 kHz, PCM 96 kSps: 2 Hz - 40 kHz, PCM 192 kSps: 2 Hz - 80 kHz, PCM 384 kSps: 2 Hz - 100 kHz.DSD 64: 2 Hz - 44 kHz, DSD 128: 2 Hz - 60 kHz, DSD 256: 2 Hz - 80 kHz

-Sampling Frequency-MP3, WMA, AAC, FLAC, OGG-Vorbis, FLAC, AIFF, ALAC, WAV, PCM 32 … 192 kHz, 16/24 Bit; MP3 up to 320 kBit

-Outputs-1 x RCA (Single Ended), 1 x XLR (Balanced)

-Digital Inputs   5x S/P-DIF: 3x standard coax (192 kSps /24 bit) and 2x optical TOSLink(96 kSps /24 bit), 1x USB: Device-Mode - up to 384 kSps / 32 bit (LPCM) and DSD256*, supports asynchronous data transfer. 2x USB master-mode for USB-mass storage devices (USB stick or VFAT formatted hard disc). * DSD256 only with a Windows PC with appropriate driver installed.

-Digital Outputs-1x coax,

-Optional Upgrades-Preamp module VVM

-Power Consumption-max. 40 W, Standby < 0,3 W

-Weight – Unit-11 KG

-Dimensions (H x W x D)-115mm x 440mm x 335mm

-Tuners/Radios-Frequency Response     FM Radio 87,5 – 108 MHz, DAB & DAB+ - 168 – 240 MHz (Band III)gs
