SERIE T/X

Overview

We have a longstanding tradition of requiring the top model in any range to be more. More than the sum of its parts, it represents the grandest scale, the highest output and the most we can do within any given technology envelope.

T/9X represents the most of T/X that we can deliver, and if sheer output alone is a primary requirement for your theater or music system then read no further. The combination of a lightweight, composite 10” driver coupled to a matching 10” T/i passive delivers speed, slam and attack when called upon but also is capable of tracing more delicate passages when necessary. Large in sonic scale, the T/9i is ideal for mating up with floor standing speakers and rooms that are on the medium-to-large size. Powerful, concussive, yet beautiful.

T/9i delivers more than just raw output. We started with our driver upgrades and built outward. The lovely cabinets grew by 4 lbs. (1.8 kg) over its predecessor due to thicker cabinet walls and improved bracing. Why? Because the additional speed and impact of the new drivers requires greater control or the benefits can be lost before they get to the listener.

The new composite alloy/fibre engine in T/9X blends precisely the correct dimension of stiffening alloy with a fibre material chosen for its sonic neutrality and light weight. The combination is brilliant; exceeding the performance of competitors’ drivers that are many times more expensive. The forward-firing 10” active couples with a 10” down-firing passive, again with carefully chosen balances of alloy to fibre and the result is seamless, effortlessly deep bass that blends perfectly with the main speakers.

Our acclaimed input filters and robust amplifiers result in some of the best sounding, most reliable designs ever produced. High current power supplies, huge toroidal transformers, and what many critics call the best filters in the world produce the famous REL Effect—where in not simply the bass region but ALL music and movie sound is uplifted and improved.

Following on the heels of the acclaimed LongBow™ Wireless, Arrow delivers much of the promise and connectivity of hardwired RELs with the placement flexibility and pure cool factor of great wireless for all of T/i. For a reasonable sum, Arrow gives you the ability to place subs in distant corners, along glass walls, or on hardwood floors where a cable would otherwise destroy the effect.

Specification

-TYPE Front-firing active driver, down-firing passive

-ACTIVE DRIVER SIZE & MATERIAL 10 in., 250mm long-throw, FibreAlloy™ inverted aluminium dust cap, steel chassis, white cone

-PASSIVE RADIATOR SIZE & MATERIAL 10 in., 250mm long-throw, inverted aluminium dust cap, steel chassis, black cone

-LOW FREQUENCY EXTENTION -6dB at 28 Hz

-INPUT CONNECTORS High Level Neutrik Speakon, Low Level single RCA, LFE RCA

-OUTPUT CONNECTORS N/A

-POWER OUTPUT 300 watts (RMS)

-AMPLIFIER TYPE Class A/B

-WIRELESS CAPABILITY Arrow (Optional), Zero Compression Single Large Scale Integrated Chip

-FULLY ELECTRONIC SET SAFE Yes

-D.C. FAULT Yes

-OUTPUT SHORT Yes

-MAINS INPUT VOLTAGE 220-240 volts, 110-120 volts for certain markets

-FUSES 3.15 Amp semi delay 230 volts operation, 6.3 Amp semi delay 115 volts operation

-W X H X D 13 x 15.2 x 16 in. (330 x 387 x 407 mm)

-NET WEIGHT 41.3 lbs. (18.7 kg)

-FINISH High Gloss Black, High Gloss White, 5 coats

-MAINS LEAD Yes

-NEUTRIK SPEAKON Yes (10 Meters Nominal)

-INTERCONNECT

-USERS MANUAL Yes
