60W X 4 Sound Quality DSP

Overview

The DSP-1 is a unique combination of a four Channel amplifier and a Digital Signal Processor in one piece. We have used uncompromising design and engineering that Massive Audio customers are accustomed to, incorporating the latest in small format technology. Not only do you get a high performance, high quality product, but you also are saving a lot of space. The same proven quality of Massive Audio lives on in the new DSP-1.

Massive Audio amplifiers are a result of years of premium craftsmanship, using on the best quality components and quality control standards. You can expect the same from your new Massive Audio DSP-1. To ensure many years of great  performance from your new DSP-1, we highly recommend you have your new DSP-1 installed by an authorized Massive Audio dealer. This will ensure the professional installation and will add One (1) Year to your Massive Audio manufacturer’s warranty.

Specifications

• RMS Power at 14.4V
• 2OHM Load 80w x 4
• 4OHM Load 60w x 4
• Input Level 1~10V (Hi Inputs or Low Inputs)
• Frequency Response  10HZ~20KHZ
• LPF/HPF 20HZ~20KHZ
• Sub Sonic Filter 20HZ~20KHZ
• THD at 40HM Load 30% Rated Power <0.05%
• S/N Ratio >95DB
• BassBoost Level 0~18DB
• BassBoost Freq 20HZ~20KHZ
• Best Efficiecy @4OHM >90%
• Minimum Load 2OHM
• Optional Remote N/A
• Auto Turn On Yes
• Low Voltage Protection Yes, Protect <8V
• Short Circuit Test Max Power Pass
• Recommended External Fuse 10A
• Overheat Protect Temperature Protect At 86C/186.8F
• Height 1.6”
• Width 4.2”
• Length 6.5”
